Buchi Rotavapor® R-180 System, with glass assembly
BUCHI Launch Offers: Evaporation System
Experience reliability and simplicity throughout your daily workflow. The Rotavapor® R-180 offers robust performance, intuitive design, and essential safety features, making it a smart addition to any laboratory.
Evaporating flask size: up to 3 L
Lift mechanism: electric
Temperature range: up to 95 °C
Key Features
Built to last
Engineered for durability, the Rotavapor® R-180 features a reliable IP42 rating for protection against water splashes. A robust aluminum base guarantees exceptional stability, and its chemical-resistant cover ensures longevity even under harsh laboratory conditions.
Well-suited for daily applications
The R-180 supports flasks up to 3 L and is available with four condenser options, including back-feeding, making it adaptable to a wide range of applications. To save valuable lab space, the instrument can be positioned at an angle for direct access, with the rotatable interface allowing clear visibility.
Safe operation: Smooth Electric Lift
Experience safety in the lab. The electric lift ensures smooth and precise height adjustments, automatically lifting the flask in the event of a power outage to protect your samples. Additionally, the glassware with Safety Coating prevents sample loss in case of accidental breakage.
Cable and tube holders
Cordless bath
Intuitive user interface
Multifunctional Combi-Clip
Space saving design
Brand: Buchi
Model no.: Rotavapor® R-180
Scope of Delivery: Rotavapor® R-180 Base Unit with glass assembly
| Component | Quantity |
| Rotavapor® R-180 Main Unit | 1 |
| Heating Bath R-180 | 1 |
| Condenser (according to order code) | 1 |
| Vapor Duct (with Combi-Clip) | 1 |
| Vacuum Seal (VS22) | 1 |
| Receiving flask (1 L) | 1 |
| Set of required cooling/vacuum tubes and connectors |
1 |
| Power Cable | 1 |
Technical Specifications
| Specification | Value |
| Dimensions (W x D x H) |
450 x 350 x 645 mm |
| Weight |
12 kg (Base unit with V condenser) |
| Heating Power |
1,300 W |
| Heating Bath Temp. Range |
Up to 95°C |
| Temp. Adjustment Accuracy |
±1 °C |
| Heating Bath Capacity |
4.2 L |
| Max. Flask Size |
3,000 mL |
| Rotation Speed Range |
10 - 330 rpm |
| Lift Mechanism |
Electric (180mm height adjustment) |
| IP Rating |
IP42 (Protection against dripping water) |
| Power Consumption |
1,500 W |
| Certification |
CB, CE, UL/CSA |
